Grasslands Observatory : Operations



Looking North from the observatory during the day At the gate looking South to the Observatory

Earth's Shadow Earth's Shadow
Earth's shadow at sunset January 22, 2011 Earth's shadow at sunset April 6, 2013 Earth's shadow at sunset June 27, 2014 Late August early evening overhead Milky Way

Achernar culminating on the Southern Horizon 4 November 2005, 11:20 pm MST; Altitude 1 deg, Azimuth 182 deg; Magnitude 0.54 Gacrux (the top star in the Southern Cross) culminating on the Southern Horizon 18 May 2007 9:40 pm MST; Altitude 0.5 deg, Azimuth 184 deg; Magnitude 1.65 The Grasslands Observatory May 18, 2007 Venus and the Moon May 18, 2007

Achernar culminatiing on December 10, 2014 Space alien Suns rays Owl on All Sky Camera
Achernar culminating on the Southern Horizon December 10, 2014 at 8:45 pm MST Space alien? Probably Western Meadowlark sitting on All Sky Camera All Sky Camera view of Sun's rays shining through clouds Another space alien? Probably an owl sitting on the All Sky Camera

Sun Halo Moon Halo on January 18, 2016 Moon halo January 19, 2016 Winter Milky and Zodiacal Light
Sun halo on January 18, 2016 at 11:51 am MST Moon halo on January 18, 2016 at 8:46 pm MST Moon halo on January 19, 2016 at 8:11 pm MST Winter Milky Way the Zodiacal Light on February 29, 2016

Moon halo on the evening of January 4, 2017
Moon halo on January 4, 2017 at 7:56 pm MST

Night at the Grasslands Observatory.


The Director of the Observatory is James McGaha who is a retired Air Force Major and a former C-130 pilot. He has a Master's degree in astronomy as well as an MBA degree. James directs the scientific program at the Observatory, which consists of asteroid astrometry, asteroid recovery, asteroid discovery, and supernova photometry.

Since 1995, the telescope and its associated instruments have been operated from the Control Room. This building was originally a small, one-room, well insulated house with lights, heat!!, a refrigerator, microwave, futon, chairs, and a Control Console for operating the telescope. The Control Console is connected by cables running through a metal conduit to the main Observatory Building. The Control Room Computer is networked to three computers in the Observatory Building, the Telescope Computer, the ACE Computer, and the Guider Computer.

In late 2013 and early 2014, the Control Room was significantly expanded to the west so that it now measures 14 x 26 feet (outside dimensions). The windows were removed, and the door situated to the south out of the path of the main wind direction. A heavy duty door with a heavy duty screen was installed. Added to the expanded Control Room is a large separate Storage Room for infrequently used tools and spare equipment. Most of the large accumulated tools and equipment (such as fence post driver, fence posts, pickaxe, spare wood beams, and tarps) were removed from the Observatory Building and placed in the Storage Room vastly improving the look and cleanliness in the Observatory Building itself.



Control Room new addition
The Control Room new addition

Looking south at the Grasslands Observatory Control Console Control Room and Observatory Building Storage Room
Looking south at the Grasslands Observatory Control Console Control Room and Observatory Building Control Room and Storage Room

The 24-inch f/5 telescope is fully computerized. It formerly had to be manually moved from position to position. Now, it is completely operated from the Control Room by a sophisticated control system installed by Astronomical Consultants & Equipment, Inc. (A.C.E.) of Tucson, Arizona. This system allows for accurate all sky pointing of the telescope, and it has a built in periodic worm correction encoder. It works in conjunction with an SBIG ST-402 ME CCD camera for long exposure guiding. In addition, a new mirror cell with built in tube fans was constructed for the telescope by A.C.E., and Losmondy mounting plates were installed on the telescope to carry a variety of instruments.

Ancillary equipment includes an 8-inch f/4 Meade LXD75 Schmidt-Newtonian telescope which has been mounted onto the side of the 24-inch telescope. Imaging through the 8-inch telescope is done with a Canon 20Da or 60Da digital camera back.  In addition, a Takahashi Epsilon f/2.8 180 Astrograph is available for mounting on the 24-inch telescope.

An Apogee AP7 CCD camera was used for imaging until September 2000. Among its accomplishments was the imaging of all 338 Arp Galaxies and tri-color imaging of all the Messier Objects. In September 2000, the AP7 camera was replaced by a Fingers Lake Instrumentation Dream Machine CCD. Prior to the AP7, an HPC-1 camera had been used, and some of its images are still posted on this web site. The HPC-1 was a very fine camera with 12 micron pixels and a 1024 x 1024 pixel array. Its quantum efficiency was good in the red and green portions of the spectrum, but it had a relatively low quantum efficiency in the blue portion of the spectrum. The Apogee AP7 camera has a very sensitive SITe 512 x 512 chip with 24 micron pixels. It was attached to an ISIS FW1 filter wheel containing an open slot, a clear filter, and standard R, V, B, and I (near-infrared) Photometric filters. Now, the Fingers Lake Instrumentation Dream Machine CCD camera is combined with a Finger Lakes CFW-1 Color Filter Wheel using Photometric R, V, and B filters as well as a Clear (C) parfocal filter. The AP7 gave a field of view of 14 minutes. The Dream Machine has a chip with a similar quantum efficiency as the AP7, but the chip is twice as large (1024 x 1024) and gives a nearly 28 minute field of view.

Focusing is performed with an Optec TCF (Temperature Compensating) digital electric focuser. At the Control Console, a Control Room Computer running under Windows XP is networked to the three computers in the Observatory Building, the Telescope Computer, The ACE Computer, and the Guider Computer. The Observatory Building computers operate the telescope, the CCD camera, the filter wheel, the focuser, and other ancillary equipment. The Telescope Computer in the observatory operates the Dream Machine CCD camera and the filter wheel.  The ACE Computer controls the telescope pointing and drive system using the sophisticated A.C.E. control system.  The Dream Machine CCD camera is controlled with MaxIm DL/CCD. The CCD is oriented on the telescope such that all images are displayed on the computer screen with the North to the top and East to the left.

The Guider Computer is also networked to the Control Room Computer, the ACE Computer, and the Telescope Computer. It runs the software and hardware for an SBIG ST 402 ME CCD camera mounted on a Celestron 8-inch f/10 telescope. The C-8 is attached to the 24-inch telescope, and the ST 402 ME guider is used for long exposures to correct periodic error drift and other drive errors. The Dream Machine CCD camera creates images that are over two megabytes in size. These are read from the CCD camera to the Telescope Computer. In order to take the raw data home for processing, a CD disk writer on the Telescope Computer is used to make data disks for long term archival storage and for taking data home.



Telescope at night Dream Machine CCD Camera Telescope with CCD Camera





tbh, Saturday 28 April 2007; revised 5 June 2014; revised Augus 28, 2014; further revision scheduled.





Take Time to Smell the Flowers:


This wild flower was photographed at 1:20am on 14 April 2001 by James McGaha with his new digital camera. We noticed the wild flower as we were returning from a night's observing run. The flower grew alongside the dirt road going back to the observatory building. It was visible in our car headlights. The entire 20 acres of property at the Grasslands Observatory was covered by these flowers. Mike Newberry of Mirametrics, Inc. (Mira) writes: "The flower James photographed is Oenothera caespitosa, or "evening primrose". "Caespitose" means growing in clumps or tufts. The flower opens in evening twilight and withers in morning twilight, lasting only 1 night. Other flowers or flowers on other plants will open the next night. It grows at 3000 to 7500' elevation in gravelly places. About 20 species of Oenothera are in Arizona."
